Multi Conductors CSA Approved 300V TPU Sheathed Customized Control Cable

Name: Multi Conductors CSA Approved 300V TPU Sheathed Customized Control Cable
Brand: Halogen Free Cable
Price: 0.28 USD

Brand Name : Halogen Free Cable

Model Number : TH-880219

Certification : UL, CSA, AWM

Place of Origin : Dongguan, China

MOQ : 3050 meters

Price : USD0.28~0.55 per meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10,000,000 meters monthly

Delivery Time : 10 days for ready goods

Packaging Details : 915 meters per carton, subject to the customized dimensions of product.

Category : Customized Cable

Feature : CSA Approved

Rated : 80C degree, 300V

Conductor : Oxygen free copper wires

Jacket : TPU materials

Standard : 100% RoHS Compliant

Contact Now

Multi Conductors CSA Approved 300V TPU Sheathed Customized Control Cable

Customized Cable is the most featured products of Tongheng business. Multi Conductors CSA Approved 300V TPU Sheathed Customized Control Cable is created strictly following customers requirement. As the professional manufacturer, Tongheng staff engage to create customer the best quality cable. Multi Conductors CSA Approved 300V TPU Sheathed Customized Control Cable is one of the excellent example. Its remarkable advantage is CSA approved with TPU sheathed.

Here below is the product properties:

Category: customized TPU cable

Type: multi conductors cable

Rated voltage: 300V

To be customized per customers request.

Product parameters:

TPU Cable	Conductor Structure	Insulation Thickness	Nominal Diameter	Screened Coverage	Sheath Thickness	Overall Diameter	Conductor Resistance
TPU Cable	No/mm	mm	mm	%	mm	mm	Ω/KM(20℃)
2C	7/0.100	0.23	0.80	≥65	0.89	3.80	381.00
2C	7/0.127	0.23	0.90	≥65	0.89	4.10	239.00
2C	7/0.16	0.23	1.00	≥65	0.89	4.30	150.00
2C	11/0.16	0.23	1.10	≥65	0.89	4.40	94.20
2C	17/0.16	0.23	1.30	≥65	0.89	4.80	59.40
2C	21/0.178	0.23	1.50	≥65	0.89	5.20	36.70
2C	34/0.178	0.23	1.80	≥65	0.89	5.80	23.20
2C	26/0.25	0.23	2.00	≥65	0.89	8.00	14.60
3C	7/0.100	0.23	0.80	≥65	0.89	5.70	381.00
3C	7/0.127	0.23	0.90	≥65	0.89	5.90	239.00
3C	7/0.16	0.23	1.00	≥65	0.89	6.10	150.00
3C	11/0.16	0.23	1.10	≥65	0.89	6.30	94.20
3C	17/0.16	0.23	1.30	≥65	0.89	6.70	59.40
3C	21/0.178	0.23	1.50	≥65	0.89	7.20	36.70
3C	34/0.178	0.23	1.80	≥65	0.89	7.80	23.20
4C	7/0.100	0.23	0.80	≥65	0.89	5.90	381.00
4C	7/0.127	0.23	0.90	≥65	0.89	6.10	239.00
4C	7/0.16	0.23	1.00	≥65	0.89	6.40	150.00
4C	11/0.16	0.23	1.10	≥65	0.89	6.70	94.20
4C	17/0.16	0.23	1.30	≥65	0.89	7.10	59.40
4C	21/0.178	0.23	1.50	≥65	0.89	7.60	36.70
5C	7/0.100	0.23	0.80	≥65	0.89	6.20	381.00
5C	7/0.127	0.23	0.90	≥65	0.89	6.50	239.00
5C	7/0.16	0.23	1.00	≥65	0.89	6.60	150.00
5C	11/0.16	0.23	1.10	≥65	0.89	7.00	94.20
5C	17/0.16	0.23	1.30	≥65	0.89	7.60	59.40
6C	7/0.100	0.23	0.80	≥65	0.89	6.60	381.00
6C	7/0.127	0.23	0.90	≥65	0.89	6.90	239.00
6C	7/0.16	0.23	1.00	≥65	0.89	7.20	150.00
6C	11/0.16	0.23	1.10	≥65	0.89	7.50	94.20

Multi Conductors CSA Approved 300V TPU Sheathed Customized Control Cable

Multi Conductors CSA Approved 300V TPU Sheathed Customized Control Cable

Contact:

Thanks for your visit to our website. The above displayed parameters are just for reference. Please ask us for customized ones immediately if you have the differentt requirement.
